Spun PP Filter Cartridge 5 micron
Terdapat banyak stock dan berbagai ukuran micron dan panjang
· Brand ; PFI Filtration
· Model ; HMBF
· Micron Size ; 1 micron, 3 micron, 5 micron, 10 micron, 25 micron, 50 micron, 75 micron, 100 micron, 125 micron, 150 micron & 200 micron
· Length ; 10” , 20” , 30” , 40”
· Diameter ; 2.5” & 4.5”
· Materials ; Spun polypropylene Filter Cartridges
Untuk informasi ketersediaan barang dan harga silahkan hubungi 0818807696
Spun Bonded Filter Cartridges are made of 100% polypropylene fibers. These fibers have been carefully spun together to form a true gradient density from outer to inner surface. Spun Bonded Filter Cartridges are available with core and without core version. The superior structure remains integral even under severe operating conditions and is no media migration. Polypropylene fibers are blown continuous on central molded core, without the need for binders, resins or lubricants. Operation unfiltered fluid passes through depth filter matrix, enables the progressive retention of finer particles, providing high efficiency, high dirt retention, and filter life. Fluid flows from outside to inside through filter media. Particulates are held securely in the filter matrix and clean fluid flows to the downstream side of cartridge.
Filter Features
100 % Polypropylene for wide chemical compatibility
Excellent flow with low pressure drop
Excellent flow with low pressure drop
High strength & pressure resistance
Nominal & absolute filtration rating
Free of surfactants, Binders and Adhesives
High dirt holding capacity
One piece construction up to1016 mm. and more
Spun PP Filter Cartridge 5 micron
Technical Specifications
Sizes : 10”,20”,30”40” Long
Inner Diameter : 25mm , 28 mm ,48 mm
Outer Diameter : 64 mm (2.5”) , 114mm (4.5”) , 6” , 8”
Micron Rating : 0.5 , 1 , 5, 10, 25, 50 , 75 , 100
Configuration
Double Open Type (DOE Type)
Code 7 (226 O Ring Design)
Construction
Spun bonded filter cartridges are made up of 100% Polypropylene
