ROPV R8040B1200S-4 Pressure Vessel
Filter Indonesia adalah importir distributor agen dan supplier FRP ROPV R8040B1200S-4 Pressure Vessel Membrane Part Housing terlengkap menyediakan berbagai kebutuhan spare part filter untuk keperluan industry dengan kualitas dan harga terbaik.
Info lengkap Housing RO Membrane
Description ROPV Pressure Vessel
As a safety precaution the housings are designed for a full body leak at 4 times the design pressure to keep catastrophic failure from happening. ROPV Pressure Vessels are designed to provide safe operation over a long service life if properly installed, operated, and maintained. The vessel may cause loss of life, severe bodily harm, or property damage if improperly installed, operated, or maintained. Read and understand all guidelines provided in the vessel User Manual. Observe every precaution contained therein. It is recommended that only qualified technicians experienced in servicing hydraulic systems work with this vessel. Misuse, incorrect assembly, or use of damaged/corroded components may result in catastrophic failure. ROPV Pressure Vessels are design and manufacture in accordance with the American Society of Mechanical Engineers, ASME, Section X Boiler and Pressure vessels Code ments, for use as a membrane element housing.
Specification ROPV
8inch Side Port FRP Membrane Housing 1200PSI
Side Port Size: 1.5’, 2’, 2.5’ clamp available
Permeate port: 1’ NPT
Port material: SS2205/SS2507
Length: (1-7) x 40inch
Designed pressure: 1200PSI (21bar)
Pressure vessel for 8inch RO, NF and UF membranes.
Key Features
Operating Temp Range: -10°C –49°C (14°F-120°F)
Pressure test: Standard— 1.1x Design Pressure, ASME— 1.5x Design Pressure
Internal permeate port not to exceed 125PSI(0.88MPa)
Operating pH Range: 3 – 11
Please operate in accordance with User Guide
Untuk informasi lebih lanjut tentang produk dan penawaran harga ROPV R8040B1200S-4 Vessel Membrane silahkan hubungi kantor kami.
