PPSG-020-WS-PD5 Filter Bag Polypropylene 6x20 inch 20 micron

PT PROFILTER INDONESIA adalah importir distributor agen dan supplier PFI PPSG-020-WS-PD5 Filter Bag Polypropylene 6x20 inch 20 micron terlengkap menyediakan berbagai kebutuhan spare part filter untuk keperluan industry dengan kualitas dan harga terbaik.

Produk filter bag kami lengkap tersedia stock untuk berbagai aplikasi cairan baik itu air maupun minyak ataupun santan.

Description PPSG Filter Bag Polypropylene 6x20 inch 20 micron

PFI PPSG Polypropylene filter bag is an effective and economical way of making bags from polypropylene which are sewn or welded and made similar to bags with holes only on the top side which function as filters for sediment, coarse and fine particles and turbidity in liquid products.

The Extended Life PFI filter bags (PE and PP) provide outstanding performance on many types of contaminants such as gels, particles with wide ranges of sizes, and particles with various irregular shapes. The coarse, pre-filtering layer is designed to provide long service life, capturing a large amount of contaminants without excess surface loading. The PEB Series has been field-proven to hold up to twice the amount of contaminants as a standard felt bag, reducing waste volume and bag changes. The Extended Life filter bag is ideal for automotive coatings, chemicals, resins, edible oils and other fluid applications.

Features

Excellent filtration on many contaminants - gels, particles with wide range of sizes and particles with irregular shapes
A coarse inner layer, graded pore structure, greater depth than standard bags provides excellent filtration performance
Available in polyester (PE) and polypropylene (PP)
Twice the standard dirt-holding capacity of traditional felt bags to provide longer service life, fewer change-outs and reduced waste
Polypropylene bags are FDA compliant
Micron rating for polypropylene 5 – 150 and polyester 1 – 150
PolyWeld seam construction with hermetically sealing PolyLoc / sentinel / Plastic ring eliminates liquid bypass
Glazed finish eliminates unwanted fiber migration

Specifications

Available Materials
- Polypropylene
- Polyester
- Nylon
Maximum Operating Temperature
- Polypropylene: 200-220° F (93-104° C)
- Polyester: 275-325° F (135-162° C)
- Nylon : 257° F (125° C)
Suggested Differential Pressure 35 PSIG maximum — dirty 10-15 PSIG optimum change out
Micron Rating
- PE = 1 until 150
- PP = 1 until 150
- NMO = 50 until 800
Sizes
- #1 : 7” x 17”
- #2 : 7” x 32”
- #3 : 4” x 9”
- #4 : 4” x 15”
- #5 : 6” x 20”
Plastic PolyLock Rings and Zinc Plate Steel Ring
Welded Seam and Stitched Seam Construction
