GF Signet 3-2751-3 DryLoc Submersible pH/ORP Smart Sensor - Akurasi Tinggi & Integrasi Fleksibel untuk Sistem Kalibrasi Industri
GF Signet 3-2751-3 DryLoc pH/ORP adalah alat pengukur kalibrasi lapangan berbasis teknologi dirancang untuk memberitahu operator industri tentang kegagalan probe atau kebutuhan perawatan. Dengan keunggulan respon cepat, akurasi tinggi, dan kompatibilitas digital/analog, alat ini sangat ideal untuk aplikasi Industrial Water Treatment, Chemical Processing, Oil & Gas, dan Power Plant.
The pH/ORP Smart Sensor Electronics will allow for calibration of electrodes in a laboratory setting and installation of pre-calibrated probes in the field, reducing system downtime.
Memory chip enabled electrodes will store operational data such as minimum and maximum pH/mV readings, runtime, minimum and maximum temperature (pH only), for troubleshooting and operational evaluation. To take full advantage of all features and benefits of the 2751, use with types 9900 (Generation IV or later), 9950 Transmitter or 0486 Profibus Concentrator.
The 2751 self-configures for pH or ORP operation via automatic recognition of the electrode type. The optional EasyCal feature allows simple push-button calibration and s an LED indicator for visual feedback. The 2751 pH/ORP Smart Sensor Electronics available for submersible and inline installations.
Features GF Signet 3-2751-3 DryLoc Submersible pH/ORP
- Probe health monitoring, glass impedance and broken glass detection
- Memory chip interface that allows for transferable calibration, runtime data, and manufacturing information
- In-line integral mount and submersible installation versions
- Automatic pH temperature compensation
- Auto configuration for pH or ORP operation
- Optional EasyCal calibration aid with automatic pH buffer recognition for 4, 7 and 10 pH and ORP solutions: quinhydrone saturated pH 4 or 7 buffers and Light’s Solution +469 mV
- Patented DryLoc connector provides a quick and secure connection to the sensor**
Spesifikasi
General
- Compatible Electrodes
- DryLoc® pH and ORP Electrodes, types 2724-2726, 2734-2736, 2744-2747, 2756-2757 Wet-Tap, 2774-2777
- Operating Range
- pH -1 to 15 pH
- ORP ±2‘000 mV
- Response Time
- pH Electrode dependent
- ORP Application dependent
- Materials
- In-line PBT (thermal plastic polyester) and polypropylene (retaining nut)
- Submersible CPVC
Max. Temperature/Pressure Rating
- Operating Temperature
- Submersible 0 °C to 85 °C 32 °F to 185 °F
- In-line 0 °C to 85 °C 32 °F to 185 °F
- Storage Temperature -20 °C to 85 °C -4 °F to 185 °F
- Relative Humidity 0 to 95%, non-condensing (without electrode connected)
Kenapa Pilih GF Signet pH/ORP dari PFI Filtration?
- Sensor original & resmi dari Georg Fischer (GF+ USA)
- Daya tahan tinggi, akurasi andal di lingkungan ekstrem
- Support teknis & integrasi sistem oleh tim berpengalaman
- Pengiriman cepat & garansi resmi
Applications
- Water and Wastewater Treatment
- Neutralization Systems
- Scrubber Control
- Effluent Monitoring
- Surface Finishing
- Flocculent Coagulation
- Heavy Metal Removal and Recovery
- Toxics Destruction
- Sanitization Systems
- Pool & Spa Control
- Aquatic Animal Life Support Systems
Untuk informasi lebih lanjut perihal produk dan penawaran harga GF Signet 3-2751-3 DryLoc Submersible pH/ORP silahkan hubungi CS kantor kami.
